Haro Double Peak 29 Trail

Haro Double Peak 29 Trail
This item is currently not available.


The Double Peak 29" Trail model features a low stand-over height frame with low center of gravity made from X6 series alloy, with an internal head tube and internal cable routing. The DP Trail model features a new Shimano Altus 2x9 drive train, versatile and capable of handling a wide variety of terrain. It glides along on 29" double wall rims, stainless spokes and 2.2" tires. The front end features a Suntour XCT-30 100mm fork with hydraulic lockout. The Trail appreciates speed, but it can stop on a dime thanks to its Shimano MT-200 Hydraulic disc brake set.

- Double Peak 6000 Series alloy frame w/ internal routing
- Suntour XCT-30 HLO 100mm travel fork
- New Shimano MT101-2 crankset, 36/22T, 2x9, w/ sealed cartridge BB
- New Shimano Altus M2020-M, 2x9 front derailleur
- New Shimano Altus M2000 9-spd rear derailleur
- New Shimano Altus SL-M2010 2x9 shifters
- Shimano HG-200 9-spd 11-36T cassette
- XD-180 alloy DW rims
- Shimano MT-200 hydraulic disc brakeset, Center Lock


Frame Haro Double Peak 29.0" X6 series alloy, w/ Internal housing routing & chainstay disc brake mount
Fork SR Suntour XCT-30 29x100mm travel w/ hydraulic lockout
Headset 1-1/8" Threadless for 50mm OD headtube w/ 15mm top cover
Rims/Wheels XD-180 alloy double wall 29"
Hubs Shimano TX-505 alloy, Center Lock Disc, cassette 32h
Tires H-5129 29 x 2.2
Crankset New Shimano MT-101, 2x9-Spd
Chainrings 36/22T
Bottom Bracket Shimano Sealed cartridge
Chain KMC Z9 9-spd
Front Derailleur New Shimano Altus, FD-M2020, 2x9-spd, Top Swing
Rear Derailleur New Altus M2000 9-spd, Shadow design
Cassette/Rear Cogs Shimano HG-200 9-spd 11-36T
Shifters New Shimano SL-M2010-2L, 2x9-spd
Handlebars Pivit alloy 15mm riser bar 31.8mm
Tape/Grips WTB Trail II
Stem Pivit forged stem
Brake Levers Shimano BL-MT200
Brakes Shimano BR-MT200 hydraulic, 160mm Center Lock Rotors
Pedals FPD Nylon body, Chromoly axles, Platform
Saddle New Haro Double Peak
Seat Post Pivit alloy micro adjust 31.6mm
Accessories & Extras Internal housing routing

* Subject to change without notice.
